$73.85 / EA
Local stock: 0
Lead time:
1
-
2
working days
Eaton Bussmann series FWX high speed fuse, 600V, 50A RMS, 200 kAIC Vac, 50 kAIC at 250 Vdc, Non Indicating, High speed fuse, Blade end X blade end, Stud
Eaton Bussmann series FWX high speed fuse, 600V, 50A RMS, 200 kAIC Vac, 50 kAIC at 250 Vdc, Non Indicating, High speed fuse, Blade end X blade end, Stud
High speed fuses provide superior protection or isolation for components such as diodes, silicon con...150
High speed fuses provide superior protection or isolation for components such as diodes, silicon controlled rectifiers (SCRs), Gate torn-Off Thyristors (GTOs) and IGBTs and in light and heavy harsh DC traction applications as high as 4000Vdc and 10,000A. Also used for the protection of DC link/power converters. Optimized dimensions and materials allow for excellent thermal dissipation for high current cycling enviroments, or heavy duty applications.
- UPC
- 051712150583
- UNSPSC
- 39121628
- Country of Origin
- MX
- Amperage Rating:
- 50A RMS
- Size:
- 0.81 In Diameter X 3.19 In Length
- Type:
- High speed fuse
- Voltage Rating:
- 600 V
- Amperage Rating:
- 50A RMS
- Connection:
- Blade end x blade end
- Dimensions:
- 3.4400 IN X 0.9100 IN X 0.8900 IN
- Height:
- 0.89 in
- Interrupt Rating:
- 200 kAIC Vac50 kAIC at 250 Vdc
- Length:
- 3.44 in
- Mounting:
- Stud, Flush
- Size:
- 0.81 In Diameter X 3.19 In Length
- Standard:
- CSA Certified ,UL Recognized,RoHS Compliant,CE Marked
- Sub Brand:
- Bussmann Series
- Type:
- High speed fuse
- Voltage Rating:
- 600 V
- Weight:
- 0.12 lb
- Width:
- 0.91 in
