Killark Electrical Products FXCS-2K3C4 Push Button Switch product image

Killark Electrical Products FXCS-2K3C4 Push Button Switch product image view 2

Image colors may not be accurate.
Please see details, or call (800) 462-7733 for more information.

Videos & documents

Documents

Warranty Url Spec Sheet

FXCS-2K3C4

SKU: FXCS-2K3C4

MPN: FXCS-2K3C4

Purchase options

$475.81 / EA

Available to order

Lead time: over 7 working days

Lead time: over 7 working days
Secure checkout with protected order handling.
Single-unit ordering available.

Dale Electric Supply ships electrical products across the U.S. and supports international orders through customer service. Local delivery may be available in defined regional delivery zones, and larger same-manufacturer orders may qualify for factory-direct shipping. Shipping and fulfillment can vary by product, vendor, manufacturer program, stock state, destination, quantity, and quote workflow.

Customer Service International Sales Factory Direct Shipping

Hill Electric Supply

Established 1948

Secure checkout and protected order handling
Phone support for compatibility and stock questions

Need cross-reference help?

Send us the SKU, manufacturer, photo, or catalog reference. We can cross-reference, confirm availability, and help source hard-to-find electrical supplies.

Contact support Browse catalog Search products

Key specs

View all

Action: SP
Amperage Rating: 275m/550m/2.5 A
Number Of Poles: 1
Size: 6-13/16" H x 3-11/16" W x 4-13/32" D
Type: Aluminum factory sealed box and cover with 3-position key selector switch
Voltage Rating: 600 VAC

Description

Product overview

FXCS SERIES - ALUMINUM DEAD-END MAINTAINED CONTACT 3-POSITION KEYEDSELECTOR SWITCH CONTROL STATION - FACTORY SEALED - KEYED DIFFERENT WITHKEY REMOVAL IN ALL THREE POSITIONS - "HAND - OFF - AUTO"/BLANK NAMEPLATE- HUB SIZE 3/4 INCH - 1NO/1NC CONTACT RATING

Manufacturer highlights

Additional manufacturer notes

Feed description: KLRK FXCS-2K3C4 BOX CVR 3POS KEYED
Invoice description: BOX CVR 3POS KEYED 3/4" DEAD 1NO/1NC

Specifications

UPC: 783936201344

UNSPSC: 39122216

Country of Origin: US

Action: SP

Amperage Rating: 275m/550m/2.5 A

Number Of Poles: 1

Size: 6-13/16" H x 3-11/16" W x 4-13/32" D

Type: Aluminum factory sealed box and cover with 3-position key selector switch

Voltage Rating: 600 VAC

Action: SP

Actuator: 3-position key selector switch

Amperage Rating: 275m/550m/2.5 A

Contact Configuration: 1-NO/1-NC

Contact Rating: 60A INRUSH @ 120 VAC; 30A INRUSH @ 240 VAC; 15A INRUSH @ 480 VAC; 12A INRUSH @ 600 VAC; 6A BREAKING @ 120 VAC; 3A BREAKING @ 240 VAC; 1.5A BREAKING @ 480 VAC; 1.2A BREAKING @ 600 VAC; 10A CARRYING @ 120 VAC; 10A CARRYING @ 240 VAC; 10A CARRYING @ 480 VAC;

Enclosure: Aluminum factory sealed dead-end splice box

Environmental Conditions: Hazardous locations

Number Of Poles: 1

Size: 6-13/16" H x 3-11/16" W x 4-13/32" D

Standard: UL, CSA

Sub Brand: SEAL-X

Type: Aluminum factory sealed box and cover with 3-position key selector switch

Voltage Rating: 600 VAC

Rate this product

Do you have a question about FXCS-2K3C4?

Videos & documents

Documents

Warranty Url Spec Sheet

G SERIES - ALUMINUM LONG 120V PILOT LIGHT OPERATOR - GREEN LENS WITHBLANK NAMEPLATE

$259.80 / EA

Available to order

View details

Specification comparison

Scan the attributes that differ across these alternatives.

GO1-KX1C N34 View key specs

SKU: GO1-KX1C N34
Price: $272.23 / EA
Availability: Available to order
Action: SPST
Actuator: Momentary push button
Amperage Rating: —
Color: —
Connection: —
Contact Configuration: 1-NO

View full product details

GO113 N34 View key specs

SKU: GO113 N34
Price: $326.76 / EA
Availability: Available to order
Action: —
Actuator: —
Amperage Rating: —
Color: —
Connection: —
Contact Configuration: —

View full product details

PD-6ANS-WH View key specs

SKU: PD-6ANS-WH
Price: $68.73 / EA
Availability: 1 available
Action: —
Actuator: Tapswitch
Amperage Rating: 3.6/6 A
Color: White
Connection: Wire Leads
Contact Configuration: N-O

View full product details

GOL4R3CN View key specs

SKU: GOL4R3CN
Price: $807.24 / EA
Availability: Available to order
Action: SP
Actuator: Pilot light and momentary push button
Amperage Rating: 25m A
Color: —
Connection: —
Contact Configuration: 1-NO/1-NC

View full product details

GO5-2A3F N34 View key specs

SKU: GO5-2A3F N34
Price: $425.63 / EA
Availability: Available to order
Action: SPST
Actuator: 2-position selector switch
Amperage Rating: —
Color: —
Connection: —
Contact Configuration: 1-NO/1-NC

View full product details

GOB3-G23C N34 View key specs

SKU: GOB3-G23C N34
Price: $259.80 / EA
Availability: Available to order
Action: —
Actuator: Pilot light
Amperage Rating: 25m A
Color: —
Connection: —
Contact Configuration: —

View full product details

Attribute	GO1-KX1C N34 G SERIES - ALUMINUM LONG MOMENTARY CONTACT SINGLE PUSH BUTTON OPERATOR -BLACK BU...	GO113 N34 G SERIES - ALUMINUM LONG SINGLE-TURN POTENTIOMETER/RHEOSTAT OPERATOR	PD-6ANS-WH Caseta Wireless switch, 6A lighting or 3.6 A fan, 120V in white	GOL4R3CN G SERIES - ALUMINUM ATEX CERTIFIED EXTENDED 120V ILLUMINATED PUSHBUTTON(PUSH TO...	GO5-2A3F N34 G SERIES - ALUMINUM LONG MAINTAINED CONTACT 2-POSITION SELECTOR SWITCHOPERATOR -...	GOB3-G23C N34 G SERIES - ALUMINUM LONG 120V PILOT LIGHT OPERATOR - GREEN LENS WITHBLANK NAMEPL...
Price	$272.23 / EA	$326.76 / EA	$68.73 / EA	$807.24 / EA	$425.63 / EA	$259.80 / EA
Availability	Available to order	Available to order	1 available	Available to order	Available to order	Available to order
Action	SPST	—	—	SP	SPST	—
Actuator	Momentary push button	—	Tapswitch	Pilot light and momentary push button	2-position selector switch	Pilot light
Amperage Rating	—	—	3.6/6 A	25m A	—	25m A
Color	—	—	White	—	—	—
Connection	—	—	Wire Leads	—	—	—
Contact Configuration	1-NO	—	N-O	1-NO/1-NC	1-NO/1-NC	—
Contact Rating	60A INRUSH @ 120 VAC; 30A INRUSH @ 240 VAC; 15A INRUSH @ 480 VAC; 12A INRUSH @ 600 VAC; 0.55A INRUSH @ 125 VDC; 0.275A INRUSH @ 250 VDC; 6A BREAKING @ 120 VAC; 3A BREAKING @ 240 VAC; 1.5A BREAKING @ 480 VAC; 1.2A BREAKING @ 600 VAC; 0.55A BREAKING @ 125 VDC; 0.275A BREAKING @ 250 VDC; 10A CARRYING @ 120 VAC; 10A CARRYING @ 240 VAC; 10A CARRYING @ 480 VAC; 10A CARRYING @ 600 VAC; 2.5A CARRYING @ 125 VDC; 2.5A CARRYING @ 250 VDC.	—	6/3.6 A	60A INRUSH @ 120 VAC; 30A INRUSH @ 240 VAC; 15A INRUSH @ 480 VAC; 12A INRUSH @ 600 VAC; 0.55A INRUSH @ 125 VDC; 0.275A INRUSH @ 250 VDC; 6A BREAKING @ 120 VAC; 3A BREAKING @ 240 VAC; 1.5A BREAKING @ 480 VAC; 1.2A BREAKING @ 600 VAC; 0.55A BREAKING @ 125 VDC; 0.275A BREAKING @ 250 VDC; 10A CARRYING @ 120 VAC; 10A CARRYING @ 240 VAC; 10A CARRYING @ 480 VAC; 10A CARRYING @ 600 VAC; 2.5A CARRYING @ 125 VDC; 2.5A CARRYING @ 250 VDC.	60A INRUSH @ 120 VAC; 30A INRUSH @ 240 VAC; 15A INRUSH @ 480 VAC; 12A INRUSH @ 600 VAC; 0.55A INRUSH @ 125 VDC; 0.275A INRUSH @ 250 VDC; 6A BREAKING @ 120 VAC; 3A BREAKING @ 240 VAC; 1.5A BREAKING @ 480 VAC; 1.2A BREAKING @ 600 VAC; 0.55A BREAKING @ 125 VDC; 0.275A BREAKING @ 250 VDC; 10A CARRYING @ 120 VAC; 10A CARRYING @ 240 VAC; 10A CARRYING @ 480 VAC; 10A CARRYING @ 600 VAC; 2.5A CARRYING @ 125 VDC; 2.5A CARRYING @ 250 VDC.	—
Enclosure	—	—	Plastic	—	—	—
Environmental Conditions	Hazardous locations	Hazardous locations	—	Hazardous locations	Hazardous locations	Hazardous locations
Insulation	—	—	Plastic	—	—	—
Material	—	—	Metal/Plastic	—	—	—
Mounting	—	—	Wallbox	—	—	—
Number Of Poles	1	—	1	1	1	—
Operating Cycles	—	—	—	10,000 hrs	—	10,000 hrs
Size	1-1/4" H x 1-1/4" W x 4-5/16" L	2-3/16" H x 2-3/16" W x 4-1/2" L	4.69 in (119 mm) x 2.94 in (75 mm)	1-13/16" H x 1-13/16" W x 6-11/16" L	1-1/4" H x 1-1/4" W x 4-3/4" L	1-35/64" H x 1-35/64" W x 5-3/8" L
Standard	UL, CSA	CSA	cUL, NOM, FCC, ICC, COFETEL	UL, CSA, ATEX	UL, CSA	UL, CSA
Sub Brand	—	—	Caseta Wireless	—	—	—
Type	Long style push button operator	Long style potentiometer/rheostat operator	Wireless in-wall electronic switch, multi-location, 3-way, single-pole	Extended style illuminated push button operator	Long style 2-position selector switch operator	Long style pilot light operator
Voltage Rating	600 VAC	600 VAC	120 V	110 to 120 V	600 VAC	110 to 120 V
Wattage	—	—	720 W	3 W	—	3 W
