HFXD63M250
SKU: HFXD63M250
MPN: HFXD63M250
Key specs
View all- Number Of Poles
- 3
- Type
- HFXD6
- Voltage Rating
- 600//500 VAC//VDC
Description
Product overview
SIEMENS LOW VOLTAGE SENTRON MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETICTRIP UNIT. ASSEMBLED 50DEG C CALIBRATED BREAKER FD FRAME WITH HIGH BREAKING CAPACITY. 250A 3-POLE (25KAIC AT 600V) (65KAIC AT 480V). NON-INTERCHANGEABLE TRIP UNIT. SPECIAL FEATURES NO LUGS INSTALLED. DIMENSIONS (W x H x D) IN 4.50 x 9.5 x 4.00.
SIEMENS LOW VOLTAGE SENTRON MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETICTRIP UNIT. ASSEMBLED 50DEG C CALIBRATED BREAKER FD FRAME WITH HIGH BREAKING CAPACITY. 250A 3-POLE (25KAIC AT 600V) (65KAIC AT 480V). NON-INTERCHANGEABLE TRIP UNIT. SPECIAL FEATURES NO LUGS INSTALLED. DIMENSIONS (W x H x D) IN 4.50 x 9.5 x 4.00.
Manufacturer highlights
Additional manufacturer notes
- Short name
- S-A
- Feed description
- S-A HFXD63M250 CIRCUIT BREAKER HFD6
- Invoice description
- CIRCUIT BREAKER HFD6 3P 600V 250A FX 50C
Specifications
- UPC
- 783643966260
- UNSPSC
- 39121601
- Country of Origin
- MX
- Number Of Poles
- 3
- Type
- HFXD6
- Voltage Rating
- 600//500 VAC//VDC
- Actuator
- Varying
- Enclosure
- Varying
- Frame
- FD
- Frequency Rating
- 400 Hz
- Height
- 11 in
- Interrupt Rating
- 25KAIC
- Length
- 7.000
- Number Of Poles
- 3
- Operating Temperature
- 50C
- Standard
- HACR
- Sub Brand
- Sentron
- Trip Range
- 1100-2500
- Trip Type
- Thermal-Magnetic
- Type
- HFXD6
- Voltage Rating
- 600//500 VAC//VDC
- Width
- 6.000
