JXD63B300HAESA
SKU: JXD63B300HAESA
MPN: JXD63B300HAESA
Key specs
View all- Material
- N/A
- Number Of Poles
- 3
- Type
- JXD6
- Voltage Rating
- 600//250 VAC//VDC
Description
Product overview
SIEMENS LOW VOLTAGE SENTRON MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETICTRIP UNIT. ASSEMBLED 100 PERCENT RATED STANDARD 40 DEG C BREAKER JD FRAME WITH STANDARD BREAKING CAPACITY. 300A 3-POLE (25KAIC AT 600V) (35KAIC AT 480V). NON-INTERCHANGEABLE TRIP UNIT. SPECIAL FEATURES NO LUGS INSTALLED. ACCESSORIES INCLUDED (S16JLD62A). DIMENSIONS (W x H x D) IN 7.50 x 11.0 x 4.00.
SIEMENS LOW VOLTAGE SENTRON MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETICTRIP UNIT. ASSEMBLED 100 PERCENT RATED STANDARD 40 DEG C BREAKER JD FRAME WITH STANDARD BREAKING CAPACITY. 300A 3-POLE (25KAIC AT 600V) (35KAIC AT 480V). NON-INTERCHANGEABLE TRIP UNIT. SPECIAL FEATURES NO LUGS INSTALLED. ACCESSORIES INCLUDED (S16JLD62A). DIMENSIONS (W x H x D) IN 7.50 x 11.0 x 4.00.
Manufacturer highlights
Additional manufacturer notes
- Short name
- S-A
- Feed description
- S-A JXD63B300HAESA BRKR JD6 3P 300A
- Invoice description
- BRKR JD6 3P 300A FX 100 12V ST 240V AUX
Specifications
- UPC
- 783643479623
- UNSPSC
- 39121601
- Country of Origin
- MX
- Material
- N/A
- Number Of Poles
- 3
- Type
- JXD6
- Voltage Rating
- 600//250 VAC//VDC
- Actuator
- S16JLD62A Accessory
- Auxiliary Contacts
- N/A
- Connection
- N/A
- Enclosure
- Varying
- Environmental Conditions
- N/A
- Frame
- JD
- Frequency Rating
- 50/60 Hz
- Height
- 13 in
- Interrupt Rating
- 25KAIC
- Length
- 7.000
- Load Rating
- N/A
- Material
- N/A
- Number Of Poles
- 3
- Operating Temperature
- 40C
- Standard
- UL/HACR
- Sub Brand
- Sentron
- Trip Range
- 1250-2500
- Trip Type
- Thermal-Magnetic
- Type
- JXD6
- Voltage Rating
- 600//250 VAC//VDC
- Width
- 9.000
