LD63B500PAESBBF
SKU: LD63B500PAESBBF
MPN: LD63B500PAESBBF
Key specs
View all- Material
- N/A
- Number Of Poles
- 3
- Type
- LD6
- Voltage Rating
- 600 V
Description
Product overview
SIEMENS LOW VOLTAGE SENTRON MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETICTRIP UNIT. ASSEMBLED STANDARD 40 DEG C BREAKER LD FRAME WITH STANDARD BREAKING CAPACITY. 500A 3-POLE (25KAIC AT 600V) (35KAIC AT 480V). INTERCHANGEABLE TRIP UNIT. SPECIAL FEATURES LOAD LUGS ONLY (TA2J6500) WIRE RANGE 3/0AWG - 500KCMIL (CU)/ 4/0AWG - 500KCMIL (AL). ACCESSORIES INCLUDED (S07JLD62A) / (B01JLD64). DIMENSIONS (W x H x D) IN 7.50 x 11.0 x 4.00.
SIEMENS LOW VOLTAGE SENTRON MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETICTRIP UNIT. ASSEMBLED STANDARD 40 DEG C BREAKER LD FRAME WITH STANDARD BREAKING CAPACITY. 500A 3-POLE (25KAIC AT 600V) (35KAIC AT 480V). INTERCHANGEABLE TRIP UNIT. SPECIAL FEATURES LOAD LUGS ONLY (TA2J6500) WIRE RANGE 3/0AWG - 500KCMIL (CU)/ 4/0AWG - 500KCMIL (AL). ACCESSORIES INCLUDED (S07JLD62A) / (B01JLD64). DIMENSIONS (W x H x D) IN 7.50 x 11.0 x 4.00.
Manufacturer highlights
Additional manufacturer notes
- Short name
- S-A
- Feed description
- S-A LD63B500PAESBBF BRKR LD6 3P 500
- Invoice description
- BRKR LD6 3P 500A LEL 24V ST AUX 480V BA
Specifications
- UPC
- 783643434998
- UNSPSC
- 39121601
- Country of Origin
- MX
- Material
- N/A
- Number Of Poles
- 3
- Type
- LD6
- Voltage Rating
- 600 V
- Actuator
- S07JLD62A and 480 Vac Form C Bell Alarm Accessories
- Auxiliary Contacts
- N/A
- Connection
- Load side lugs only
- Enclosure
- Varying
- Environmental Conditions
- N/A
- Frame
- LD
- Frequency Rating
- 50/60 Hz
- Height
- 15 in
- Interrupt Rating
- 25KAIC
- Length
- 7.000
- Load Rating
- N/A
- Material
- N/A
- Number Of Poles
- 3
- Operating Temperature
- 40C
- Standard
- UL/HACR
- Sub Brand
- Sentron
- Trip Range
- 3000-6000
- Trip Type
- Thermal-Magnetic
- Type
- LD6
- Voltage Rating
- 600 V
- Width
- 9.000
