SIEMENS LOW VOLTAGE SENTRON MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETICTRIP UNIT. ASSEMBLED STANDARD 40 DEG C BREAKER LD FRAME WITH STANDARD BREAKING CAPACITY. 600A 2-POLE (25KAIC AT 600V) (35KAIC AT 480V). NON-INTERCHANGEABLE TRIP UNIT. SPECIAL FEATURES LINE AND LOAD SIDE LUGS (TA2J6500) WIRE RANGE 3/0AWG - 500KCMIL (CU) / 4/0AWG - 500KCMIL (AL). ACCESSORIES INCLUDED (S11JLD62A). DIMENSIONS (W x H x D) IN 7.50 x 11.0 x 4.00.
SIEMENS LOW VOLTAGE SENTRON MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETICTRIP UNIT. ASSEMBLED STANDARD 40 DEG C BREAKER LD FRAME WITH STANDARD BREAKING CAPACITY. 600A 2-POLE (25KAIC AT 600V) (35KAIC AT 480V). NON-INTERCHANGEABLE TRIP UNIT. SPECIAL FEATURES LINE AND LOAD SIDE LUGS (TA2J6500) WIRE RANGE 3/0AWG - 500KCMIL (CU) / 4/0AWG - 500KCMIL (AL). ACCESSORIES INCLUDED (S11JLD62A). DIMENSIONS (W x H x D) IN 7.50 x 11.0 x 4.00.

Image colors may not be accurate.
Please see details, or call (800) 462-7733 for more information.

LXD62B600LAESD

$16,551.43 / EA

manufacturer discounts
learn about discounts

  • $14,839.21 for $1,500.00+
  • $14,268.48 for $2,500.00+
  • $13,697.74 for $3,500.00+
Available to order

Local stock: 0
Lead time: over 7 working days

SIEMENS LOW VOLTAGE SENTRON MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETICTRIP UNIT. ASSEMBLED STANDARD 40 DEG C BREAKER LD FRAME WITH STANDARD BREAKING CAPACITY. 600A 2-POLE (25KAIC AT 600V) (35KAIC AT 480V). NON-INTERCHANGEABLE TRIP UNIT. SPECIAL FEATURES LINE AND LOAD SIDE LUGS (TA2J6500) WIRE RANGE 3/0AWG - 500KCMIL (CU) / 4/0AWG - 500KCMIL (AL). ACCESSORIES INCLUDED (S11JLD62A). DIMENSIONS (W x H x D) IN 7.50 x 11.0 x 4.00.

SIEMENS LOW VOLTAGE SENTRON MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETICTRIP UNIT. ASSEMBLED STANDARD 40 DEG C BREAKER LD FRAME WITH STANDARD BREAKING CAPACITY. 600A 2-POLE (25KAIC AT 600V) (35KAIC AT 480V). NON-INTERCHANGEABLE TRIP UNIT. SPECIAL FEATURES LINE AND LOAD SIDE LUGS (TA2J6500) WIRE RANGE 3/0AWG - 500KCMIL (CU) / 4/0AWG - 500KCMIL (AL). ACCESSORIES INCLUDED (S11JLD62A). DIMENSIONS (W x H x D) IN 7.50 x 11.0 x 4.00.

150

UPC
783643202900
UNSPSC
39121601
Country of Origin
MX
Material:
N/A
Number Of Poles:
2
Type:
LXD6
Voltage Rating:
600 V
Actuator:
S11JLD62A Accessory
Auxiliary Contacts:
N/A
Connection:
Line/Load lugs installed
Enclosure:
Varying
Environmental Conditions:
N/A
Frame:
LD
Frequency Rating:
50/60 Hz
Height:
15 in
Interrupt Rating:
25KAIC
Length:
7.000
Load Rating:
N/A
Material:
N/A
Number Of Poles:
2
Operating Temperature:
40C
Standard:
UL/HACR
Sub Brand:
Sentron
Trip Range:
3000-6000
Trip Type:
Thermal-Magnetic
Type:
LXD6
Voltage Rating:
600 V
Width:
9.000
