Q33500S01
SKU: Q33500S01
MPN: Q33500S01
Key specs
View all- Number Of Poles
- 3
- Type
- QP
Description
Product overview
Siemens Low Voltage Residential Circuit Breakers Miniature Thermal Mag Circuit Breakers - Type QP/MP, 3-Pole, 240VAC are Circuit Protection Load Center Mains, Feeders, and Miniature Circuit Breakers. Type QP/MP Special Features Shunt Trip 120V Application Electrical Distribution Standard UL 489 Voltage Rating 120/240VAmperage Rating 35A Trip Range Thermal Magnetic Interrupt Rating 10 AIC Number Of Poles 3P
Siemens Low Voltage Residential Circuit Breakers Miniature Thermal Mag Circuit Breakers - Type QP/MP, 3-Pole, 240VAC are Circuit Protection Load Center Mains, Feeders, and Miniature Circuit Breakers. Type QP/MP Special Features Shunt Trip 120V Application Electrical Distribution Standard UL 489 Voltage Rating 120/240VAmperage Rating 35A Trip Range Thermal Magnetic Interrupt Rating 10 AIC Number Of Poles 3P
Manufacturer highlights
Additional manufacturer notes
- Short name
- S-A
- Feed description
- S-A Q33500S01 BREAKER 35A 3P 240V 1
- Invoice description
- BREAKER 35A 3P 240V 10K QP 120V SHUNT
Specifications
- UPC
- 783087890510
- UNSPSC
- 39121601
- Country of Origin
- MX
- Number Of Poles
- 3
- Type
- QP
- Conductor Size
- 14-6AWG(CU)/12-6AWG(AL)
- Connection
- PLUG-IN
- Continuous current / rated value
- 35 A
- Frame
- QP(125A)
- Height [in]
- 2.87 in
- Length
- 3 in
- Number Of Poles
- 3
- Standard
- ULLISTED/CSA/NOMCERTIFIED
- Supply voltage frequency / rated value / 50/60 Hz
- TRUE
- Trip Type
- THERMAL-MAGNETIC
- Type
- QP
- Type of mounting panel
- LOADCENTER
- Voltage / between phase and phase / rated value
- 240 V
- Width
- 4 in
